CRL BP05S Metallic Silver 5″x5″ Offset Base Plate

CRL BP05S Metallic Silver 5″x5″ Offset Base Plate

C.R. Laurence BP05S Metallic Silver 5″ x 5″ Offset Base Plate is expertly designed to provide a robust foundation for your railing systems. Crafted from durable aluminum, this base plate features a silver metallic finish that not only enhances its aesthetic appeal but also ensures longevity and resistance to the elements. With a base plate diameter of 5 inches and a thickness of 3/8 inch, the BP05S offers stability and strength for 2-3/8″ (60 mm) square aluminum posts. The offset design allows for easy attachment of vertical posts, making installation straightforward and efficient. Each base plate is countersunk to accommodate four Cat. No. BPS112 Base Plate Screws, which can be secured to your substrate using appropriate concrete anchors or lag bolts. To achieve a polished look, consider pairing it with stainless steel washers (WSHR1) and color match bolt cover buttons (BTN1). Included with every base plate is a moisture barrier gasket (Cat. No. BPG1BL) for added protection against moisture intrusion. Available in seven standard colors, plus unfinished chromate for custom projects, the BP05S is an excellent choice for both professional and residential applications. Please note that this product is painted to order and is non-refundable.

Metallic Silver 5″ x 5″ Offset Base Plate

• Seven Standard Colors, Plus Unfinished Chromate Available for Standard and 45 Degree Post
• For Use with All Standard Railings
• For 2-3/8″ (60 mm) Square Aluminum Posts

CRL Standard Square Base Plates screw into Vertical Post raceways. They are countersunk to accept four Cat. No. BPS112 Base Plate Screws, then attached to the substrate with our Concrete Anchors or Lag Bolts. Use Stainless Steel Washers (WSHR1) and Color Match Bolt Cover Buttons (BTN1) to add a finished look. The BP05 Offset Base Plate design allows vertical posts to attach to one side of the Base Plate. One each Moisture Barrier Gasket Cat. No. BPG1BL is included with each Base Plate.
Product Warning:
All ARS/AWS products are painted to order and are non-refundable or returnable.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer’s video card and on how your monitor’s color is adjusted.

Attributes

Ship via: Can Ship UPS

Base Plate Diameter: 5 in. (127 mm)

Base Plate Thickness: 3/8 in. (10 mm)

Compliance and Restrictions: Warning Reproductive Harm – www.p65warnings.ca.gov

Finish/ Color:: Silver Metallic

Material: Aluminum

Shipping Limitations: None
