CRL BP05M 5″ x 5″ Offset Base Plate

CRL BP05M 5″ x 5″ Offset Base Plate

C.R. Laurence BP05M Mill 5″ x 5″ Offset Base Plate is expertly designed to provide a secure and stylish foundation for your railings. Crafted from durable aluminum, this base plate measures 5 inches by 5 inches with a thickness of 3/8 inch, ensuring robust support for your structures. It is available in several attractive colors, allowing you to customize your installation to suit any aesthetic. This base plate accommodates standard and 45-degree posts, making it versatile for various applications. Its innovative offset design allows vertical posts to attach seamlessly to one side, streamlining the installation process. Each unit is equipped with a moisture barrier gasket (Cat. No. BPG1BL) to enhance durability against the elements. For installation, the BP05M Base Plate screws into vertical post raceways using four Cat. No. BPS112 base plate screws, then fastens securely to the substrate with concrete anchors or lag bolts. To achieve a polished finish, consider pairing it with stainless steel washers (WSHR1) and color match bolt cover buttons (BTN1). Please note, all ARS/AWS products are painted to order and are non-refundable or returnable. Elevate your railing systems with the reliability and design of the C.R. Laurence BP05M Base Plate.

Mill 5″ x 5″ Offset Base Plate

• Available in Several Attractive Colors
• Available for Standard and 45 Degree Post
• For Use with All Standard Railings
• For 2-3/8″ (60 mm) Square Aluminum Posts

CRL Standard Square Base Plates screw into Vertical Post raceways. They are countersunk to accept four Cat. No. BPS112 Base Plate Screws, then attached to the substrate with our Concrete Anchors or Lag Bolts. Use Stainless Steel Washers (WSHR1) and Color Match Bolt Cover Buttons (BTN1) to add a finished look. The BP05 Offset Base Plate design allows vertical posts to attach to one side of the Base Plate. One each Moisture Barrier Gasket Cat. No. BPG1BL is included with each Base Plate.

Product Warning:
All ARS/AWS products are painted to order and are non-refundable or returnable.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer’s video card and on how your monitor’s color is adjusted.

Attributes

Ship via: Can Ship UPS

Base Plate Length: 5 in. (127 mm)

Base Plate Thickness: 3/8 in. (10 mm)

Base Plate Width: 5 in. (127 mm)

Compliance and Restrictions: Warning Reproductive Harm – www.p65warnings.ca.gov

Finish/ Color:: Mill

Material: Aluminum

Shipping Limitations: None
