Yale AU546F 689 Exit Device Trim

Yale AU546F 689 Exit Device Trim
Rose x Lever Trim, Classroom (08), Augusta Lever, Aluminum

• Certified ANSI/BHMA A156.3, Grade 1.
• Trim through-bolts to exit device for strength.
• Beveled sides improve attack resistance.
• Solid forged escutcheon and Free-Wheeling trim resists vandalism and abuse.
• Flush cylinder in 6-pin applications for additional security.
• 1-3/4″ (44mm) door standard. For doors through 2-1/4″ (57mm) or shim-mounted devices, specify on order.
• Dimensions: 3″ x 10-1/4″ x 13/16″ (76mm x 260mm x 19mm).
• Cylinders not included. 1-1/2″ mortise cylinder required for mortise trim.
• 1-1/2″ mortise cylinder required for mortise trim.
• Available with AR, AU, CR, JN, MO, PB, PN, VI, HA lever designs and CO, LF knob designs. Finishes: 605, 606, 609, 611, 612, 613, 616, 619, 620, 626, 629, 630, 693, 722
• Finishes: 605, 606, 609, 611, 612, 613, 616, 619, 620, 626, 629, 630, 693, 722
• Available with Reflections® lever designs. Finishes: 605, 606, 611, 612, 613, 619, 626, 629, 630 722
• Finishes: 605, 606, 611, 612, 613, 619, 626, 629, 630 722
• Trim ordering example: AU626F x 626 x RHR

Attributes

Ship via: Can Ship UPS

Alternate Codes: 122102, 194369, AU546F689, AU546FSB

Cylinder Type: KIK/KIL

Exit Device Type: Exit Trim

Finish: 689/US28

Finish Color: Satin Aluminum

Finish Description: Aluminum Painted

Fire Rated: No

Function: Classroom

Includes Cylinders: Yes

Series: Yale Exit Device Trim

Subtype: Exit Device Trim

Supplier: Yale

Trim Design: AU – Augusta

Trim Style: Lever, Rose

Trim Type: Classroom Lever

Type: Exit Devices
