Salice FRAKFEPWSN9 Wind Push White Hardware

Salice FRAKFEPWSN9 Wind Push White Hardware

SALICE Wind Push To Open WHITE/FREE FRAKFEPWSN9 is designed for upward-opening lids, offering a seamless and sophisticated solution that eliminates the need for additional hinges such as piano, butt, or concealed hinges. This innovative flap door lift system attaches directly to the cabinet sides, utilizing a 35mm hinge cup hole in the door, ensuring a clean and modern appearance. Accommodating a minimum door height of 8-5/8″ (220mm) and a maximum height of 24″ (610mm), this system is versatile enough for various applications. When utilizing two lid stays, the maximum door width can reach up to 48″, making it ideal for larger installations. For angled cabinets, wide or heavier doors, and five-piece doors, a top mounting bracket is available, allowing for secure installation to the cabinet ceiling. The Wind Push system offers an impressive 85° opening when a restriction clip is installed, which can be increased to 94° if removed, providing flexibility in door access. Weighing in at just 3.3 lbs, this lightweight system is easy to handle and install. Enhance your cabinetry with the reliability and style of the SALICE Wind Push To Open lift system.

Wind Push White/FREE

Salice Wind Push To Open WHITE/FREE FRAKFEPWSN9
For upward-opening lids that do not require additional piano, butt or concealed hinges

• Does not require extra hinges
• Minimum door height 8-5/8″ (220mm)
• Maximum door height 24″ (610mm)
• 85° opening with restriction clip installed, 94° if removed
• Maximum door width is 48″ when using 2 lid stays
• Flap door lift system attaches to the cabinet sides with 35mm hinge cup hole in the door
• Top mounting bracket available for angled cabinets, wide or heavier doors and 5 piece doors to mount to ceiling of cabinet

Attributes

Ship via: Can Ship UPS

Description: White / Free

Length: 8

Manufacturer: Salice

Monthly Special: No

Type: Lift System

Weight: 3.300000
