Richelieu 429220160 Concealed Steel Hinge Model 220

Richelieu 429220160 Concealed Steel Hinge Model 220

Richelieu 429220160 Concealed Steel Hinge – Model 220 combines an elegant satin brass finish with robust functionality, making it an ideal choice for both wood and metal doors. Designed for seamless integration, this hinge ensures a clean, contemporary look while providing superior durability for high-traffic applications. With a remarkable 180° hinge opening angle, the Richelieu Model 220 enhances accessibility and convenience. It features a reversible handedness design, allowing for flexible installation to accommodate various door configurations. The hinge is constructed from high-quality steel, ensuring long-lasting performance, while its fire-resistant rating of 20 minutes adds an important safety feature. Installation is straightforward, thanks to the mortise mounting type and included screws. The hinge supports a minimum door thickness of 2 inches, with a leaf body mortise length of 2 15/16 inches and a leaf gap of 1 1/16 inches. The door to jamb gap is set at 1/2 inch, with a precise 1/16 inch gap in the closed position to ensure a snug fit. Richelieu’s 429220160 hinge meets UL R13634 standards, making it a reliable choice for your architectural needs. Upgrade your projects with this functional and stylish hinge, perfect for enhancing the aesthetic and operational qualities of your doors.

Concealed Steel Hinge – Model 220

Richelieu’s concealed hinges offer superior appearance and durability with contemporary and functional style. They easily install and can be used for many applications on wood or metal doors to meet all your needs.

Attributes

Ship via: Can Ship UPS

Cabinet Angle: 180°

Center to Center (mm): 4 1/8 in

Dimension A: 1 3/8 in

Dimension B: 1 1/16 in

Dimension C: 5 1/2 in

Dimension D: 1/2 in

Dimension E: 9/32 in

Dimension F: 2 15/16 in

Dimension G: 1/16 in

Dimension H: 1 63/64 in

Dimension I: 15/32 in

Door/ Jamb Gap: 1/2 in

Door/ Jamb Gap (mm): 1/2 in

Door/ Jamb Gap in Closed Position: 1/16 in

Door/ Jamb Inset: 9/32 in

Door/ Jamb Inset (mm): 9/32 in

Finish: Satin Brass

Fire Resistant: 20 minutes

Fixing Type: Screw-On

For Hinge #: 220

Handedness: Reversible

Height: 1 63/64 in

Hinge Opening Angle: +180º

Leaf Body Mortise Length: 2 15/16 in

Leaf Gap: 1 1/16 in

Leaf Mortise Depth: 15/32 in

Length: 5 1/2 in

Material: Steel

Minimum Door Thickness: 2 in

Mounting Type: Mortise

Product #: 429220160

Product number: 429220160

Product №: 429220160

Screw/ Nail: Screw/Nail (Included)

Standards and Certifications: UL R13634

Type of Hinge: Wood or Metal

Width: 1 3/8 in

Wood Screw Sizes: #12 x 1-1/2″ (5.5 mm x 38 mm)
