Name: Nova Pro 22" Drawer Member 4-3/4" H Metallic Grass 65165-04
SKU: 65165-04_A
Availability: InStock

Nova Pro 22″ Drawer Member 4-3/4″ H Metallic Grass 65165-04

Nova Pro is a double walled, steel drawer system concealing a synchronized rack and pinion full extension and soft close drawer slide
The Grass exclusive rack and pinion mechanism:
1) Eliminates noise associated with moving metal parts2) Significantly reduces side-to-side play 3) Provides outstanding load ratings of either 88 or 154 lb.
The Grass “Airmaticin soft close system is seamlessly integrated into each slide
Sleek contoured drawer sides are finished in a two step process that consists of a color base coat and a fingerprint resistant top coat, drawer sides are available in Champagne finished
Two drawer side heights are available: 3-1/2″ and 4-3/4″, for deep drawers with taller fronts, side and divider railings can be added to improve cabinet organization
Drawer fronts are two way adjustable: side-to-side +/- 1mm (1/32″), and up and down +/- 2mm (2/32″)
The standard Nova Pro unit is packaged in three individual parts: pairs (left and right) of cabinet/slide member in six lengths (11″ to 22″), pairs of (left and right) drawer side members in six lengths (11″ to 22″) and drawer front brackets in screw and dowel versions

Product details

Manufacturer

: GRASS AMERICA

SKU	: 10782471

Manufacturer’s Part

: 65165-04

Weight

: 4.890 lbs

Sold in Multiples of

: 1

Priced By

: Set

Preorder

: N

Product Type

: Drawer Member Set

Product Finish

: Metallic

Length (Actual)

: 22″

Includes

: Drawer Member Set (Left and Right)
