Imperial TH1190-RH-AL Intermediate Pivot

Imperial TH1190-RH-AL Intermediate Pivot

Imperial USA TH1190-RH-AL Intermediate Pivot offers a reliable solution for both flush face frame installations and 1/8″ recessed door applications. Designed specifically for aluminum doors weighing up to 125 pounds, this pivot is engineered for durability and ease of installation, making it a top choice for professionals and discerning homeowners alike. Featuring a 3/4″ offset design, the TH1190-RH-AL is weather-resistant and constructed from high-quality aluminum for enhanced longevity. The full race ball bearing at the bottom pivot ensures smooth operation, while the pivot’s unique design eliminates sagging, allowing the entire weight of the door to rest on the floor-mounted pivot portion. Vertical adjustment capabilities of 1/8″ further enhance its adaptability. This pivot is completely tamper-proof yet can be easily removed or replaced in an unlocked position, providing both security and convenience. Handed for right-side installation, it is available in a sleek aluminum finish (AL) and can be complemented with the non-handed top portion (1110-T). Perfect for a variety of settings, the Imperial USA TH1190-RH-AL Intermediate Pivot is an essential component for robust door functionality.

Intermediate Pivot

Notice: The info below is not item specific.

Offset door pivots are used for both flush face frame installation and 1/8″ recessed door applications. Door pivots replace most major door manufactures. These door pivots are suitable for aluminum doors weighing up to 125 pounds. These door pivots are engineered and designed for durability, style and are easy to install.

Features:

• 3/4″ offset pivots for aluminum doors and frames
• For flush door / frame and 1/8″ recessed door applications
• Weather resistant
• Aluminum case construction
• Vertical adjustment 1/8″
• Full race ball bearing and design, provides smooth operation on bottom pivot door portion
• No sag, entire weight of doors rests on floor mounted pivot portion
• Completely temper proof, yet easily removable, replaceable in unlocked position
• Top portions available 1110-T non handed
• All pivots are handed- specify LH, RH

Finishes:

• DU – Duronodic
• AL – Aluminum

Attributes

Ship via: Can Ship UPS

Alternate Codes: TH1190-RH-AL, TH1190RHAL

Category: Hinges, Pivots

Door Application: Pivots

Finish Code: AL

Finish Color: Aluminum

Handing: Right Handed

Hinge Rating: 125 lbs

Hinge Style: Square Corner

Hinge Type: Intermediate, Offset Pivot

Manufacturer: Global Door Controls
