Imperial TH1100-INT-AL Intermediate Pivot Set

Imperial TH1100-INT-AL Intermediate Pivot Set

Imperial USA TH1100-INT-AL Intermediate Pivot Set is designed specifically for taller doors, exceeding 83 inches, offering crucial support to maintain proper alignment with the top and bottom pivots. This pivot set excels in both flush face frame installations and 1/8″ recessed door applications, making it a versatile choice for various projects. However, please note that it is not suitable for center hung doors. Crafted from precision aluminum diecast, this pivot set can support aluminum doors weighing up to 125 pounds, ensuring durability and reliability. The 3/4″ offset application enhances its functionality, while the full race ball bearing paired with an Oilite bronze bushing provides smooth operation. For doors up to 90″ in height, a single intermediate pivot is advisable, with an additional pivot recommended for every extra 30″ of height. Installation is made straightforward with a fully retractable case-hardened pin and easy vertical adjustment. The TH1100-INT-AL is available in two finishes: Duronodic and Aluminum, allowing for seamless integration into any design scheme. With its robust construction and intelligent design, this intermediate pivot set is an essential component for ensuring the longevity and performance of your door systems.

Intermediate Pivot Set

Notice: The info below is not item specific.

Intermediate pivots are intended for doors taller than 83″ that require additional support to keep the middle of the door in line with the pivots at the top and bottom. For use on both flush face frame installations and 1/8″ recessed door applications. The pivots cannot be used on center hung doors. Suitable for aluminum doors weighing up to 125 pounds.

Features:

• 3/4″ offset application
• Precision aluminum diecast
• Doors up to 90″ in height should use one intermediate pivot. We recommend another intermediate pivot for each additional 30″
• Full race ball bearing and Oilite bronze bushing
• Case hardened pin to jamb portion fully retractable for ease of installation on the TH1120 / TH1121 only
• Door thickness: 1-3/4″
• Easy vertical adjustment

Finishes:

• DU – Duronodic
• AL – Aluminum

Attributes

Ship via: Can Ship UPS

Alternate Codes: IMPTH100-INT-AL, TH100-INT-AL, TH100INTAL, TH1100-INT-AL, TH1100INTAL

Category: Hinges, Pivots

Door Application: Pivots

Finish Code: AL

Finish Color: Aluminum

Hinge Rating: 125 lbs

Hinge Style: Beveled

Hinge Type: Intermediate, Offset Pivot

Manufacturer: Global Door Controls
