Imperial ED-VR531-AL Surface Vertical Rod Exit Device 36in

Imperial ED-VR531-AL Surface Vertical Rod Exit Device 36in

Imperial USA ED-VR531-AL Surface Vertical Rod Exit Device 36in offers a robust and stylish solution for high-traffic commercial environments. Designed to accommodate doors up to 36 inches wide, this exit device features a sleek stainless-steel finish and is compatible with both hollow metal and wood doors. Standing at a height of 7 feet, it can be conveniently cut down to fit narrower doors, with an optional 12-inch extension rod available for taller installations. This exit device meets rigorous ADA compliance standards and exceeds ANSI Grade 1 certification, ensuring reliability in demanding applications such as office buildings, retail spaces, and hotels. The VR531 series combines a vertical rod mechanism with a modern aesthetic, making it a practical choice for any setting. It includes a top and bottom latch, while the exterior lever trim is sold separately. Installation is straightforward, with all necessary hardware included. The device features easy dogging with a hex key, and it’s designed for both non-handed and reversible applications, providing flexibility during installation. With a projection of 2-1/4 inches and a durable build, the Imperial USA ED-VR531-AL is a secure and attractive option for your exit needs. Enjoy peace of mind with a one-year mechanical and finish warranty.

Surface Vertical Rod Exit Device 36in

Notice: The info below is not item specific.

The VR531 series surface vertical rod panic exit device comes in a stainless-steel finish and is compatible with doors up to 36 in. wide and can be cut as needed for narrower doors. It fits doors 7 feet high, but a 12-inch extension rod (ED-ROD12) is available for purchase. This exit device blends the utility of a vertical rod application with the appearance of a modern style panic device. It is ADA compliant and exceeds ANSI standards for grade 1, making it the perfect fit for any commercial and industrial applications where heavy usage is anticipated, such as office buildings, retail spaces and hotels. Includes top & bottom latch, but the exterior lever trim is sold separately.

Features:

• ANSI A156.3 Grade 1 – non fire rated
• Fits 7-foot doors – 12″ extension rod available for purchase
• Compatible with hollow metal and wood doors 26″ to 36″ wide
• Available in XL: up to 48″
• Set up for dogging & includes dogging hex key
• EAK500: Alarm kit
• Projection: 2-1/4 in.
• Door thickness: 1-3/4 to 2 in.
• Stile (head width) of 3 in. minimum
• Comes with standard strike and shim
• Can be cut down to 26″ in length
• Easy installation, all mounting hardware included
• Plastic end cap/spring loaded latches
• UL Listed SA32524
• ADA Compliant
• Non handed/reversible
• 1 year mechanical and finish warranty

Finishes:

• US32D – Stainless steel
• DU – Duronodic
• AL – Aluminum

Attributes

Ship via: Can Ship UPS

Alternate Codes: ED-VR531-AL, EDVR531-AL, EDVR531AL, IPLED-VR531-AL*, TACED-VR531-AL, VR531-AL

Bar Style: Push Bar

Category: Panic Devices, Panic Devices & Exit Alarms

Certifications: A156.3, ADA, ANSI, UL listed SA32524

Device Width: 36″

Dogging: HD – Hex Dogging

Door Application: Panic Devices

Door Height: 84″

Door Thickness: 1-3/4″-2″

Door Type: Hollow Metal, Wood

Door Width: 26-36″

Exit Device Category: Surface vertical rod

Finish Code: AL

Finish Color: Aluminum

Function: Exit

Grade: Grade 1

Handing: Non-Handed, Reversible

Keying: Hex Key Dogging

Manufacturer: Trans-Atlantic Co

Series: ED-500 Series

Stile Width: 3in Minimun
