Dormakaba LR101126D Right Hand Mechanical Pushbutton Lever Lock, 2-3/4″ Backset, Satin Chrome

Dormakaba LR101126D Right Hand Mechanical Pushbutton Lever Lock, 2-3/4″ Backset, Satin Chrome

Simplex LR101126D Right Hand Mechanical Pushbutton Lever Lock offers a robust solution for controlling access between public and private spaces. Designed without the need for keys, cards, or batteries, this fully mechanical lock ensures convenience and reliability. The combination can be changed easily in seconds without the need to remove the lock from the door, making it ideal for busy environments. This lock features a single access code that simplifies management for all users, paired with vandal-resistant solid metal pushbuttons that enhance durability. The LR101126D is compatible with both wood and metal doors, requiring ASA 161 door preparation and additional through holes for easy installation.With a backset of 2-3/4″ and a crossbore size of 2-1/4″, this lock is suitable for door thicknesses ranging from 1-3/8″ to 2-1/4″. Finished in satin chrome, it not only provides security but also complements various architectural styles. The return lever design adds a touch of elegance while ensuring functionality. Backed by a 3-year limited warranty, the Simplex LR101126D combines quality craftsmanship with innovative technology, making it a top choice for mechanical pushbutton locksets.

Right Hand Mechanical Pushbutton Lever Lock Combination Only 2-3/4″ Backset Satin Chrome Finish

Simplex mechanical pushbutton locks offer a convenient way to control access between public and private areas. There are no keys or cards to manage, no computers to program, no batteries to replace, and combinations can be changed in seconds without removing the lock from the door.

• Fully Mechanical Lock Eliminates the Material and Labor Expense of Battery Replacements
• Single Access Code—One Easy-to-Manage Code for All Users
• Lock is Easily Programmed Via Keypad Without Removing Lock From the Door
• Vandal Resistant, Solid Metal Pushbuttons
• Easily Installs on Wood or Metal Doors. ASA 161 Door Preparation with Additional Through Holes
• Locking Device: Cylindrical latch with 3-hour UL/ULC fire rating on “A” labeled doors
• Number of Codes: Single access code-one easy-to-manage code for all users
• Programming: Lock is easily programmed via keypad without removing lock from the door
• Handing: Factory-handed; not field reversible
• Key Override (Optional):
• Interchangeable Cores: Small format-Best and equivalents (6 or 7-pin length); core not included
• Removable Cores: Large format-Medeco/ASSA/Yale/Abloy (5 or 6-pin length); Corbin Russwin (6-pin length); Schlage, and Sargent; core not included
• Operation Modes:
• Pushbutton Access
• Passage (select models)-allows access without using the lock entry code. Feature activated from the inside with a thumbturn or key (included with all passage feature models).
• Privacy (select models)-disables the lock from the inside so that the entry code cannot be used to gain access. Access is permitted using the key override only when in this mode.
• Economical: A cost effective access control solution

Attributes

Ship via: Can Ship UPS

Access Type: Mechanical

Alternate Codes: 119597, 881888, LR101126D

Backset: 2-3/4″ Backset

Category: Mechanical Commercial Locksets

Crossbore Size: 2-1/4″ Bore

Design: Simplex Lever

Dimension: 3-1/8″ x 7-3/8″; 3-13/16″ Projection

Door Range: 1-3/8″ to 2-1/4″

Door Thickness: 1-3/4″ – 2-1/4″

Finish: Satin Chrome

Finish Code: 26D

Finish Color: Satin Chrome

Function: Combination Entry

Handing: Right Hand

Hazardous Material: NO

Knob/ Lever Style: Lever

Latch Faceplate Dimension: 1-1/8″ x 2-1/4″

Lever Knob Design: Return Lever

Lock Category: Cylindrical Lock

Manufacturer Warranty: 3 Year Limited Warranty

Material: Cast Zinc

No Of Inners: 1

Order_ Qty: 1

PO date: 2024-09-11

Proximity Format: Pushbutton Combination

Series: L1000 Series

Strike: Standard Strike Plate; ASA Strike Plate

Strike Dimension: 1-1/4″ x 4-7/8″

Subcategory: Mechanical Pushbutton Locksets

Subtype: Mechanical Pushbutton

Type: ACCESS CONTROL

Upc: 036448803675
