Dormakaba E2031LL626 Eplex Electronic Pushbutton Lock, 1/2″ Throw, 2-3/4″ Backset, Satin Chrome

Dormakaba E2031LL626 Eplex Electronic Pushbutton Lock, 1/2″ Throw, 2-3/4″ Backset, Satin Chrome

Simplex Dormakaba E2031LL626 Eplex Cylindrical Electronic Pushbutton Lock combines security and convenience in a sleek satin chrome finish. Designed for commercial use, this electronic lock features a 1/2″ throw and a 2-3/4″ backset, ensuring a robust and reliable locking mechanism for various applications. The long lever design enhances accessibility, making it an ideal choice for high-traffic areas. With a cylindrical chassis, the E2031LL626 is compatible with cylindrical locksets and supports door thicknesses ranging from 1-3/4″ to 2-1/4″. The lock is fire-rated, meeting UL10C standards, which provides additional peace of mind in emergency situations. The 2-1/8″ crossbore size simplifies installation, while the ASA strike ensures a secure fit. This model operates on a wired power supply and features a combination entry function, eliminating the need for traditional keys. A single inner mechanism enhances its security while maintaining user convenience. The latch faceplate measures 1-1/8″ x 2-1/4″, and the overall dimensions of 3-5/16″ x 8-15/16″ with a 2-1/4″ projection make it a space-efficient choice for any entry point.Upgrade your locking solution with the Simplex Dormakaba E2031LL626, where modern technology meets practical design.

Eplex Cylindrical Electronic Pushbutton Lock with 1/2″ Throw and 2-3/4″ Backset No Key Override Long Lever Satin Chrome Finish

• Locking Device Options
• Cylindrical: Cylindrical latch with 3-hour UL/ULC fire rating
• Rim Exit Device: Compatible with most leading brands of Exit Devices (Exit Device and mounting hardware not included)
• American Standard Mortise: With 1-1/4″ (32 mm) face plate; with and without deadbolt, auto deadbolt also available
• Number of Codes: Multiple Users—100 Codes
• Handing: Non-handed; pre-assembled for left-hand door installations—easily changed in the field
• Audit Trail: The most recent 1,000 Events are recorded in memory, including the use of mechanical key override. Software is required to view audit Events.
• Programming: Lock is easily programmed via keypad without removing lock from the door or with optional Microsoft® Excel®-based software
• Key Override (Optional):
• Optional Key-in-Lever cylinder in Schlage “C” Keyway with black Kaba cap
• Small format—Best and equivalent (6 or 7-pin length)
• Operation Modes:
• PIN access
• Passage—can be toggled on/off or can be pre-programmed to re-lock after a certain number of hours
• Lockout
• Authority Levels:
• Five different levels allow who has access to specific lock functions
• Service Codes—programmed for one-time access or “come-and-go” access for 1 to 24 hours
• User Parameters:
• Code length—adjustable to accept 4 to 8 digits
• Anti-tamper lockout—adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds
• Re-lock time—adjustable from 2 to 20 seconds
• Lock Power: Battery Powered – Batteries located in outside housing; offers quick and easy battery replacements (three AA Alkaline batteries provide up to 100,000 cycles); lock data is maintained if batteries fail.

Attributes

Ship via: Can Ship UPS

Access Type: Electronic

Alternate Codes: 139272, E2031LL626

Backset: 2 3/4″ Backset

Category: Commercial Electronic Devices

Chassis Type: Cylindrical Chassis

Crossbore Size: 2-1/8″ Bore

Dimension: 3-5/16″ x 8-15/16″; 2-1/4″ Projection

Door Thickness: 1-3/4″ – 2-1/4″

Finish: Satin Chrome

Finish Code: 626

Finish Color: Satin Chrome

Fire Rated: Yes

Function: Combination Entry

Grade: Grade 1

Handing: Field Reversible, Left Hand

Hazardous Material: NO

Knob/ Lever Style: Lever

Latch Faceplate Dimension: 1-1/8″ x 2-1/4″

Lever Knob Design: Long Lever

Lock Category: Cylindrical Lock

No Of Inners: 1

Order_ Qty: 1

PO date: 2024-09-17

Power Supply: Wired

Product Type Used With: Cylindrical Lockset

Proximity Format: Keypad

Series: 2000 Series

Strike: ASA Strike

Strike Dimension: 1-1/4″ x 4-7/8″

Subcategory: Commercial Electronic Locksets

Type: ACCESS CONTROL

Ul Listing Type: UL10C

Voltage: 4 AA
