CRL VPS116PS Polished Stainless 16″ Adjustable Pull Handle with VP1 Mounting

CRL VPS116PS Polished Stainless 16″ Adjustable Pull Handle with VP1 Mounting

C.R. Laurence VPS116PS Polished Stainless 16″ Variant Series Adjustable Pull Handle with VP1 Mounting Post offers a sleek and versatile solution for glass applications. Designed to accommodate a range of mounting centers from 6″ to 26-3/4″ (152 to 679 mm), this pull handle features adjustable mounting posts, making it ideal for both standard and custom installations. Constructed from durable 1″ (25 mm) diameter polished stainless steel tubing, the VPS116PS not only exudes modern elegance but also ensures long-lasting performance. It is compatible with monolithic tempered glass ranging from 3/8″ to 3/4″ (10 to 19 mm) in thickness. The handle requires two 5/8″ (16 mm) diameter holes for installation, with standard mounting options available at 12″, 18″, and 24″ (305, 457, and 610 mm) centers. Included with the handle are two through-bolts for secure glass mounting and four adjustable mounting posts (VP1 or VP2, depending on handle style). This pull handle is perfect for both commercial and residential applications, providing a seamless connection between style and functionality.Please note that while stainless steel is resistant to corrosion, periodic maintenance is recommended to preserve its factory finish. Choose the C.R. Laurence VPS116PS for a refined touch in your glass installations.

Polished Stainless 16″ Variant Series Adjustable Pull Handle with VP1 Mounting Post

• Adjustable Mounting Posts Can Mount on 6 to 26-3/4″ (152 to 679 mm) Centers
• For 3/8″ to 3/4″ (10 and 19 mm) Glass
• Constructed of 1″ (25 mm) Diameter Stainless Steel Tubing
• Use Monolithic Tempered Glass

The CRL Variant Series Adjustable Mounting Post Style Pulls are designed to fit on standard hole patterns of 12″, 18″ and 24″ (305, 457 and 610 mm) centers, but with their adjustable mounting posts our various sizes will accommodate any hole pattern ranging from 6″ up to 26-3/4″ (152 to 679 mm) on center. Additional Mounting Posts can also be purchased separately.
SPECIFICATIONS:
For Use With: 3/8″ to 3/4″ (10 to 19 mm) Glass
Construction:
1″ (25 mm) Diameter Stainless Steel Tubing
Glass Fabrication Required:
Two 5/8″ (16 mm) Diameter Holes,
VPS x 16: 12″ (305 mm) Center-to-Center
VPS x 22: 18″ (457 mm) Center-to-Center
VPS x 28: 24″ (610 mm) Center-to-Center
NOTE: Hole centers shown are for standard mounting locations. You may vary actual hole centers.
INCLUDES:
2 Each: Through-Bolts for Glass Mounting
4 Each: Adjustable Mounting Posts (VP1 or VP2 Depending on Handle Style)

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer’s video card and on how your monitor’s color is adjusted.

Stainless Steel Advisory:

Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.

Attributes

Ship via: Can Ship UPS

Compliance and Restrictions: Warning Reproductive Harm – www.p65warnings.ca.gov

Finish/ Color:: Polished Stainless Steel

Glazing Thickness: 3/8 in. To 3/4 in. (10 mm To 19 mm)

Material: Stainless Steel

Mounting Center To Center: 12 in. Adjustable (305 mm)

Mounting Hole Diameter: 5/8 in. (16 mm)

Mounting Type: Back-To-Back

Overall Length: 16 in. (406 mm)

Shipping Limitations: None
