CRL EH173 Brushed Nickel 1″ Wall Mount Set Screw Hinge

CRL EH173 Brushed Nickel 1″ Wall Mount Set Screw Hinge

C.R. Laurence EH173 Brushed Nickel 1″ Wall Mount Set Screw Hinge offers a sleek and efficient solution for glass-to-wall installations, perfect for showcase and stereo cabinets. Designed for use with 3/16″ and 1/4″ (5 mm to 6 mm) monolithic tempered glass, this hinge requires no holes or cut-outs, ensuring a clean and professional look. The innovative plastic-tipped set screws allow for a secure attachment without drilling, making installation straightforward and hassle-free. With a maximum door width of 16″ (406 mm) and a weight capacity of up to 8 lbs. (3.6 kg), this hinge is versatile enough for various applications while maintaining durability. The brushed nickel finish not only enhances the aesthetic appeal but also offers a modern touch to your cabinetry. Each pack contains two hinges along with matching finish wood screws for a seamless installation. Measuring 1″ (25.4 mm) in height and 3/4″ (19.1 mm) in width, the EH173 hinge combines both form and function. Ideal for building professionals and discerning homeowners, this product exemplifies C.R. Laurence’s commitment to quality and innovation in architectural hardware. Experience the ease of installation and elegant design with the CRL EH173 hinge.

Brushed Nickel 1″ Wall Mount Set Screw Hinge

• For 3/16″ and 1/4″ (5 and 6 mm) Glass
• No Holes or Cut-Outs Required
• Use Monolithic Tempered Glass

These CRL Hinges were designed for use in glass-to-wall showcase and stereo cabinets installations. The glass is secured with plastic tipped set screws for no-drill attachment. The maximum recommended door width is 16″ (406 mm). Maximum weight should not exceed 8 lbs. (3.6 kg). Two per pack with matching finish wood screws provided.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer’s video card and on how your monitor’s color is adjusted.

Attributes

Ship via: Can Ship UPS

Compliance and Restrictions: Warning Reproductive Harm – www.p65warnings.ca.gov

Finish/ Color:: Brushed Nickel

Glazing Thickness: 3/16 in. To 1/4 in. (5 mm To 6 mm)

Height: 1 in. (25.4 mm)

Material: Brass

Maximum Door Width: 16 in. (406.4 mm)

Pack Quantity: 2

Shipping Limitations: None

Weight Capacity: 8 lbs. (3.6 kg)

Width: 3/4 in. (19.1 mm)
