Blum 79B9698 95 Degree CLIP Top BLUMOTION Hinge, Soft-Close, +45 Diagonal, Inserta

Original price was: $7.99.Current price is: $3.20.

Add to Wishlist
Compare
79B9698_A
  • Opening angle: 95°
  • Cabinet angle: 45°
  • Cranking: Half overlay appl.
  • BLUMOTION
  • Hinge cup assembly: INSERTA
  • Hinge cup material: Steel hinge cup
  • Closing mechanism: with spring
  • Side adjustment: +/- 1.8 mm
  • Depth adjustment: +/- 2 mm, convenient with spiral screw

Product details

Manufacturer : BLUM INC
SKU : 11183426
Manufacturer’s Part : 79B9698
Weight : 0.220 lbs
Sold in Multiples of : 1
Priced By : Each
UPC/EAN Code : 9002617794649
Preorder : N
Cabinet Type : Frameless
Face Frame
Degree of Opening : 95
Overlay : Half Overlay
Closing Type : Soft-Closing
Hinge Cup MountingHow the cup is attached to the cabinet : Tool-Free
Boring Pattern SpreadHow far apart the mounting holes in the cup are spaced : 45mm
Application : Angled
Configuration : Hinge and Plate sold separately
Arm Style : Straight
Cup Diameter : 35mm
Cup Depth : 13mm
Product Type : Angled Hinge
Product Finish : Nickel Plated
Includes : (1) Hinge
Cabinet Angle : 45°
Side Adjustment : +/- 1.8 mm with Screw
Depth Adjustment : +/- 2 mm with Spiral Screw
